REED VC01 Temperature Simulator

Model: VC01

REED VC01 Temperature Simulator-

datasheet manual
Ask an Expert

REED VC01 Temperature Simulator

Model: VC01

This temperature simulator features a 6 digit LCD readout and automatic calibration.

Discontinued!

This product has been discontinued and is no longer available.
This is the direct replacement:

REED R2815 Temperature Calibrator-

REED R2815 Temperature Calibrator

Model: R2815

Sources and measures 11 thermocouple types and 5 RTD types and features a large, easy-to-read display.

Learn More

REED VC01 Offers

This REED Temperature Simulator is a powerful and easy to use calibrator that can measure and source 8 thermocouple types and 2 RTD types, plus volts and ohms, to test and calibrate almost any temperature instrument.

Features

  • 6-digit LCD readout
  • Automatic calibration
  • User selectable auto power-off

REED VC01 Specifications

Thermocouple Output Specifications
I/O Type Temperature Range Resolution Output Accuracy
R T/C -40 to 1760°C 1°C ≤100°C: ±0.5% ±3°C; >100°C: ±0.5% ±2°C
S T/C -20 to 1760°C 1°C ≤100°C: ±0.5% ±3°C; >100°C: ±0.5% ±2°C
B T/C 400 to 1800°C 1°C ≤600°C: ±0.5% ±3°C; >600°C: ±0.5% ±2°C
E T/C -200.0 to 1000.0°C 0.1°C ≤100°C: ±0.5% ±2°C; >100°C: ±0.5% ±1°C
K T/C -200.0 to 1370.0°C 0.1°C ≤100°C: ±0.5% ±2°C; >100°C: ±0.5% ±1°C
J T/C -200.0 to 1200.0°C 0.1°C ≤100°C: ±0.5% ±2°C; >100°C: ±0.5% ±1°C
T T/C -200.0 to 400.0°C 0.1°C ≤100°C: ±0.5% ±2°C; >100°C: ±0.5% ±1°C
N T/C -200.0 to 1300.0°C 0.1°C ≤100°C: ±0.5% ±2°C; >100°C: ±0.5% ±1°C
Pt100 RTD -200.0 to 850.0°C 0.1°C ±0.05% ±0.6°C
Cu50 RTD -50.0 to 150.0°C 0.1°C ±0.05% ±0.6°C
Electrical Output Specifications
Voltage Range 100mV; 1V
Voltage Output Range -10.00 to 110.00mV; -0.1000 to 1.1V
Voltage Resolution 0.01mV; 0.1mV
Voltage Accuracy ±0.05% setting ± 30µV; ±0.05% setting ± 0.3mV
Resistance Range 400Ω
Resistance Output Range 0.0 to 400.0Ω
Resistance Resolution 0.1Ω
Resistance Accuracy ±0.05% reading ± 0.2Ω
General Specifications
Power Supply Single 9V alkaline battery
Battery Life Approx. 25 hours
Dimensions 200 x 100 x 40mm w/ holster
Weight 550g w/ holster

What's included with the REED VC01

  • VC01 Temperature Simulator
  • Industrial Test Leads
  • Alligator Clips
  • Protective Holster
  • Soft Carrying Case
  • Battery
