REED R9260 Radiation Dose Meter

Model: R9260 | UPC: 800837006509

REED R9260 Radiation Dose Meter-

datasheet manual

Ask an Expert

REED R9260 Radiation Dose Meter

Model: R9260 | UPC: 800837006509

This portable radiation dose meter monitors the amount of beta, gamma, and X-rays an individual has been exposed to allowing for prompt and effective management of radiation safety.

REED R9260 Offers

This compact and lightweight device is designed to be easily carried in a pocket or attached to a belt or lanyard, making it accessible and convenient for use. The R9260 features an easy-to-read LCD display, user-adjustable alarm limits, and internal memory capable of recording up to 10 groups of data and is widely used in a variety of applications to measure and monitor exposure to ionizing radiation.

Features

Detects Beta, Gamma, and X radiation
Measures dose rate in real-time and records total doses
Automatic selection of measurement range
User-adjustable alarms (audio/visual indicators)
Internal memory stores up to 10 groups of data internally
Auto shut-off and low battery indicator

REED R9260 Specifications

Sensor Type	G-M Counter Tube
Measured Rays	Beta, Gamma, X
Radiation Dose Range	0.05µSv/h to 50mSv/h
Accumulated Radiation Dose Value	0.1µSv to 9999mSv
Accuracy	≤25%
Energy Range	80keV to 1.5MeV
Source	Cs-137
Response Time	≤10 seconds
Display	2" color TFT LCD display
Backlit Display	Yes
Adjustable Alarms	Yes (Audible/Visual Indicators)
Natural Environment Reading	0 to 0.2µSv/h
Data Logging Capabilities	Yes
Real-Time Clock and Date Stamp	Yes
Internal Memory	Yes (up to 10 groups of data)
Power Supply	Built-in lithium battery (3.7V 1800mAh)
Battery Life	Approx. 20 days (Fully Charged)
Product Certifications	CE, UKCA, RoHS
Operating Temperature	32 to 104°F (0 to 40°C)
Operating Humidity Range	20 to 80%
Storage Temperature	14 to 122°F (-10 to 50°C)
Storage Humidity Range	20 to 70%
Dimensions	4.7 x 2.6 x 1" (120 x 65 x 25mm)
Weight	4.48oz (127g)
